Monolith pinout for UFD v207

UFD v207 - new pinout

New monolith pinout for UFD v207 was added to database.

Solution model for SM2244G AC

SM2244G AC - model

Solution model for Transcend SSD with SM2244G AC controller was added to library.

Monolith USB v157 - model

Solution model for Monolith USB v157  was added to library.

Soluton model for Silicon Motion SM2236G AC

SM2236G AC - model

Solution model for Compact Flash card with SM2236G AC controller was added to library.

Monolith pinout SD v118

SD v118 - new pinout

New monolith pinout for SD v118 was added to database. It was from Lexar 633x, blue one.

Solution model for Firstchip FC2279

FC2279 - model

Solution model for Firstchip FC2279 controller was added to library.

Monolith USB_67 v3 - solution model

USB_67 v3 - model

Solution model for monolith USB_67 v3 based on DM controller was added to library.

ECC for DM from UFD monolith

ECC for DM UFD monolith

ECC for DM controller from UFD monolith was added to resources. It works for sector 1102, cover 16 sectors data area and operates on full bytes.

DM XOR for MicroSD

DM XOR for MicroSD

New XOR for DM controller from MicroSD was developed and added to resources. XOR cover 16 sectors data and ECC area with 384 pages. Sector geometry is 1144_1152 bytes and has a signature 1775CE.
