Solution model for AU blob controller

AU blob - solution model

Solution model for AU blob controller was added to library.

Solution model for SM3281L-AB

SM3281L-AB - solution model

Solution model for Silicon Motion SM3281L-AB controller was added to library.

Monolith pinout for UFD v248

UFD v248 - new pinout

New monolith pinout for UFD v248 was added to database.

Monolith pinout for MicroSD v289

MicroSD v289 - new pinout

New monolith pinout for MicroSD v289 was added to database. It is fake 512GB FranGoo card marked with MMCAX64A9T25U3-TO.

XOR for SM3265P AC

XOR for SM3265P AC

XOR for Silicon Motion SM3265P AC controller was developed and added to resources. XOR cover 16 sectors with data, has 2304 pages and signature EB2985.

Solution model for PS2251-61-5

PS2251-61-5 - solution model

Solution model for Phison PS2251-61-5 controller was added to library.

ECC for SM MicroSD

ECC for MicroSD with SM controller

ECC for MicroSD with SM controller was added to resources. It works on for geometry 32_1144 bytes -  16 data sectors and one service area, fitted to bits.

Solution model for PS2251-01-L

PS2251-01-L - solution model

Solution model for Phison PS2251-01-L controller (from SSD with USB 3.0 connector) was added to library.

Monolith pinout for UFD v247

UFD v247 - new pinout

New monolith pinout for UFD v247 was added to database.
